The SolarViper high powered LED solar lighting system comes
complete with solar power assembly, fixture, bracket and all
mounting hardware to attach to a pole. SEPCO can also provide a
pole to meet wind load specifications.
The SolarViper solar power assembly ranges from 30 Watts to
550 Watts with the size of the battery assembly allowing for a
minimum of
five days autonomy. The solar power assembly is sized
according to installation location and takes into consideration
local weather conditions.
The Viper fixture is a contemporary Cobrahead style fixture
and comes complete with LEDs and driver used to operate the
fixture from the solar charged batteries. The SolarViper ranges
from 15 to 80 Watts and comes with Type II, III, IV and V
Distribution patterns, as well as 3K, 4K and 5K color
temperatures.
The SolarViper's fixture bracket can either be a SP - Side of
Pole Bracket which is a long elliptical upsweep arm ranging from
4’ to 8’ (longer lengths are available) or a short straight ST –
Side of Pole Tenon Bracket ranging from 5” to 24”. The fixture
mounts below the solar panel at the required mounting height for
the application.
The SolarViper system mounts to any round pole with
a minimum diameter of 4", allowing the solar to face south while
not restricting the direction of fixture installation. The
system can be purchased complete with a pole for mounting the
solar lighting system. Poles are available in aluminum, steel,
fiberglass composite, or concrete and are anchor base or direct
burial. All poles provided by SEPCO meet local AASHTO wind load
requirements.
